Design System Inspired by Tinybird

1. Visual Theme & Atmosphere

Tinybird is a real-time data platform for data engineers. A vivid green accent on deep indigo-navy surfaces creates a technical but approachable environment. The design emphasises query interfaces, pipeline graphs, and API endpoint management.

Key Characteristics:

• Green on deep indigo-navy — technical and premium
• SQL and API as first-class UI elements
• IBM Plex Mono for data engineering credibility
• Always dark — the product is for night-owl data engineers

2. Color Palette & Roles

Primary

• Brand Green (#27C486): CTAs, active states, run actions
• Green Dark (#1FA070): Hover state

Accent Colors

• Yellow (#F5C518): Warnings, slow-query indicators

Neutral Scale

• Text Primary (#E8E8F0): Headings, body
• Text Secondary (#A1A1B5): Labels, metadata
• Text Muted (#5E5E7A): Placeholders

Surface & Borders

• Background (#1A1A2E): App background
• Surface (#292942): Cards, editors
• Surface Raised (#33334F): Input fields
• Border (#40405C): Dividers

Semantic / Status

• Success (#27C486): Published pipes, healthy (uses brand green)
• Error (#FF5757): Failed queries, broken pipes
• Warning (#F5C518): Slow queries, approaching limits

3. Typography Rules

Font Family

Primary: Inter, fallback: system-ui, sans-serif. Code: IBM Plex Mono

Hierarchy

Role	Font	Size	Weight	Line Height	Letter Spacing	Notes
H1	Inter	32px	700	1.2	-0.01em	Page titles
H2	Inter	22px	600	1.3	0	Section headings
H3	Inter	17px	600	1.4	0	Card titles
Body	Inter	14px	400	1.6	0	UI body
Small	Inter	12px	400	1.5	0	Labels, meta
Code	IBM Plex Mono	14px	400	1.6	0	SQL, API paths

Principles

• IBM Plex Mono is the identity typeface — use it for all code
• Keep UI text at 14px; never go below 12px

4. Component Stylings

Buttons

• Primary: bg #27C486, text #1A1A2E, padding 9px 18px, radius 6px, font 14px/600
• Secondary: bg transparent, border 1px solid #40405C, text #E8E8F0
• Danger: bg #FF5757, text #FFFFFF

Cards & Containers

• bg #292942, border 1px solid #40405C, radius 8px, padding 20px

Inputs & Forms

• bg #33334F, border 1px solid #40405C, radius 6px, padding 9px 14px, text #E8E8F0
• Focus: border #27C486

Navigation

• Left sidebar #1A1A2E, 240px
• Top nav #1A1A2E, 56px, border-bottom #292942

5. Layout Principles

Spacing System

• 4px — Icon gaps
• 8px — Node spacing in pipe graph
• 12px — Editor padding
• 16px — Card padding
• 20px — Card content
• 24px — Section gaps
• 32px — Panel separation
• 48px — Page sections

Grid & Container

• Max width 1280px. Sidebar 240px + fluid main. Pipe graph: full width.

Whitespace Philosophy

Data pipelines need visual space to show node relationships clearly.

Border Radius Scale

• None (0px): Code editor
• Sm (4px): Status badges
• Md (6px): Buttons, inputs
• Lg (8px): Cards, pipeline nodes
• Full (9999px): Status dots

6. Depth & Elevation

Level	Treatment	Use
Flat	none	Background
Raised	0 0 0 1px rgba(255,255,255,0.05)	Cards
Overlay	0 4px 16px rgba(0,0,0,0.5)	Dropdowns
Modal	0 8px 32px rgba(0,0,0,0.6)	Dialogs

7. Do's and Don'ts

Do

• Use green for run and publish actions — it signals execution
• Show query performance metrics after every run
• Keep SQL editors wide — never constrain below 600px

Don't

• Don't use green for destructive or warning states
• Don't paginate query results — stream them with virtual scrolling
• Don't hide the pipe dependency graph

8. Responsive Behavior

Breakpoints

Name	Width	Key Changes
Mobile	0–767px	View-only, no editor
Tablet	768–1023px	Collapsed sidebar
Desktop	1024px+	Full 3-panel layout

Touch Targets

Minimum 44×44px. Pipeline nodes are 48×48px minimum.

Collapsing Strategy

Sidebar collapses to icon rail. Pipe graph scrolls horizontally on smaller screens.

9. Agent Prompt Guide

Quick Color Reference

• CTA / Run: Green (#27C486) — text is dark (#1A1A2E) on green
• Background: Deep indigo (#1A1A2E)
• Surface: Card indigo (#292942)
• Text: #E8E8F0
• Border: #40405C
• Error: Red (#FF5757)

Iteration Guide

1. Green CTA text must be dark (#1A1A2E) — the green is bright enough
2. IBM Plex Mono is non-negotiable for all code and API paths
3. Cards are #292942, one step lighter than the #1A1A2E bg
4. Pipe/DAG graph nodes use card-level bg with green borders for active
5. Never use a light theme — the product is dark-only
